Timing Belt Idler Tension Spring — 1PZ, 1HZ, 1HD-T — Land Cruiser 70/80 Series, Prado (90507-27001)

Timing Belt Idler Tension Spring for the 1PZ, 1HZ & 1HD-T engines — Toyota part #90507-27001.

This compression spring maintains correct pressure on the idler pulley in the spring-type timing belt tensioner assembly. A weak, broken, or missing spring causes belt slack, timing deviation, and can lead to catastrophic engine damage. Typically replaced together with the idler pulley, tension pin, and timing belt as a complete service.

Note: For spring-type tensioner models only — not used on hydraulic tensioner variants. If unsure which type your engine has, contact us before ordering.

At a glance

• Type: Timing belt idler tension spring
• Toyota part number: 90507-27001

Engine compatibility

• 1PZ — 3.0L I5 Diesel
• 1HZ — 4.2L I6 Diesel
• 1HD-T — 4.2L I6 Turbo Diesel

Vehicle fitment

Toyota Land Cruiser (70 Series)

• Chassis: HZJ70LV, HZJ70RV, HZJ73LV, HZJ73RV, HZJ75LP, HZJ75LV, HZJ75RP, HZJ75RV, PZJ70LV, PZJ70R, PZJ70RV, PZJ73LV, PZJ73R, PZJ73RV, PZJ75LP, PZJ75LV, PZJ75RP, PZJ75RV
• Engines: 1PZ — 3.0L I5 Diesel, 1HZ — 4.2L I6 Diesel, 1HD-T — 4.2L I6 Turbo Diesel

Toyota Land Cruiser (80 Series)

• Chassis: HDJ80L, HDJ80R, HDJ81V, HZJ80L, HZJ80R, HZJ81V
• Engines: 1HZ — 4.2L I6 Diesel, 1HD-T — 4.2L I6 Turbo Diesel

Toyota Land Cruiser Prado (70 Series)

• Chassis: HZJ73HV, HZJ73V, HZJ77HV, PZJ70, PZJ70V, PZJ77HV, PZJ77V
• Engines: 1PZ — 3.0L I5 Diesel, 1HZ — 4.2L I6 Diesel, 1HD-T — 4.2L I6 Turbo Diesel

Part Numbers

Toyota OE: 90507-27001
